Panasonic‘s Daylight View Basic technology achieves sharp, easy-to-see images by clearly reproducing the details in dark image areas, which were previously difficult to see in brightly lit rooms. A built-in sensor measures the ambient light, and the Daylight View Basic function adjusts the halftone colour and brightness level according to the surrounding illumination.
Side-by-Side and P-in-P Function
Two different image sources can be simultaneously displayed onto a single screen. You can also switch to P-in-P (Picture-in-Picture) mode and display a sub-window onto the main screen. The sub-window can be positioned anywhere on the screen for more flexible and effective image presentations.
*This function is not effective for some source combinations.
DICOM Simulation Mode
This imaging mode is similar to DICOM part 14, which is a medical imaging standard. It reproduces X-ray images with remarkable clarity.
Note: This product is not a medical instrument. Do not use it for actual medical diagnosis.
Colour Adjustment Function
A colour adjustment function allows you to easily correct for slight variations in the colour reproduction range of individual units set up for multiple projection, particularly in side-by-side configuration. Correction is performed on 3 colours (R, G, B) or 7 colours (R, G, B, C, M, Y, W).
Dust-Resistant Cabinet and Eco Filter
The shielding of the lens section has been further improved to keep dust out. The sealing performance of the air filter unit and air intake duct has been increased to prevent the entry of dust resulting in a highly dust-resistant structure. The Eco Filter unit captures dust in the intake airflow path and requires no replacement for up to 17,000 hours.
Note: usage environment affects the lamp replacement cycle.
Easy Lamp and Filter Replacement
By minimising the entry of dust into the optical block, the projector maintains brightness over a long period of time, while reducing the hassle of maintenance. For easy maintenance, you can replace the filter from the side and the lamp from the top of the projector. The filter and lamp are easily replaced even after the projector is installed on the ceiling.
The wide adjustment range of the powered horizontal/vertical lens shift function assures convenience and versatility during installation. It lets you easily make adjustments with the remote control. The unit can also be rotated 360 degrees vertically. This means you can install it at any angle you want, to accommodate different installation conditions.
Crestron Connected™ and AMX Device Discovery
The LAN terminal allows a computer connected to the network to use Crestron Connected™ application software to manage and control system devices. Besides, the AMX Device Discovery technology is built in the PT-EW640 Series.
Easy Remote Monitoring
Web browser on a computer connected through a wired LAN system lets you remotely operate projectors and check their status. An e-mail messaging function can also notify you when a lamp needs replacement, and indicate the overall projector status. Multi Projector Monitoring and Control Software is available for monitoring and controlling multiple Panasonic projectors from a single PC.
Simple DIGITAL LINK Connections
Equipped with a DIGITAL LINK terminal, the PT-EW640 allows transmission of HDMI, uncompressed HD digital video, audio and control signals (Ethernet, RS-232C) for up to 100 meters (328 feet) through a single CAT5e (STP) cable or higher. This simplifies cabling and system upgrades, making it ideal for ceiling-mounted and other permanent installations.
