| Model (50Hz) |
CS-UC18RKF-5
[CU-UC18RKF-5] |
| Cooling Capacity |
Btu/h |
17200 |
| Ton |
1.5 |
| kW |
5.05 |
| EER |
Btu/hW |
9.30 |
| COP |
W/W |
2.73 |
| Electrical Data |
Voltage |
V |
230 |
| Running Current |
A |
8.21 |
| Power Input |
KW |
1850 |
| Moisture Removal |
L/h |
3.0 |
| Pt/h |
6.3 |
| Air Circulation (Indoor/Hi) |
m³/min. |
16.4 |
| ft³/min. |
579 |
| Dimensions |
Height |
mm |
290 [619] |
| Width |
mm |
1070 [824] |
| Depth |
mm |
220 [299] |
| Noise Level |
Indoor [H/L/Q-Lo] |
[dB-A] |
46/41 |
| Outdoor |
[dB-A] |
[56] |
| Net Weight |
kg |
12 [36] |
| lb |
26 [79] |
| Refrigerant Pipe Diameter |
Liquid Side |
mm / inch |
Ø6.35 / 1/4" |
| Gas Side |
mm / inch |
Ø12.70 / 1/2" |
| Pipe Extension |
Chargeless Pipe Length |
m |
7.5 |
| Maximum Pipe Length |
m |
20 |
| Additional Refrigerant Gas* |
g/m |
20 |
| Power Supply |
Indoor |
| NOTE |
* When pipes are not extended from the standard pipe length, the required amount of refrigerant is already in the unit. |
