| Model (50Hz) |
CS-YC24MKF
(CU-YC24MKF) |
| Cooling/ Heating Capacity |
Btu/h |
24000-24000
- |
| kW |
7.03-7.03
- |
| EER/ COP |
Btu/hW |
8.76 |
| Electrical Data |
Voltage |
V |
220-240 |
| Running Current |
A |
12.4 |
| Power Input |
W |
2740 |
| Moisture Removal |
L/h |
4.0 |
| Pt/h |
8.5 |
| Air Circulation (Indoor/Hi) |
m³/min. |
18.0 |
| ft³/min. |
635 |
| Dimensions |
Height |
mm |
290 (695) |
| inch |
11-7/16 (27-3/8) |
| Width |
mm |
1070 (875) |
| inch |
42-5/33 (34-15/32) |
| Depth |
mm |
220 (320) |
| inch |
8-11/16 (12-5/8) |
| Net Weight |
kg |
12 (56) |
| lb |
26 (123) |
| Refrigerant Pipe Diameter |
Liquid Side |
mm / inch |
Ø 6.35 (1/4'') |
| Gas Side |
mm / inch |
Ø 15.88 (5/8'') |
| Pipe Extension |
Chargeless Pipe Length |
m |
5 |
| Maximum Pipe Length |
m |
15 |
| Maximum Elevation Length |
m |
10 |
| Additional Refrigerant Gas* |
g/m |
30 |
| Power Supply |
Indoor |
| NOTE |
* When pipes are not extended from the standard pipe length, the required amount of refrigerant is already in the unit. |
