| CD, CD-R/ -RW*1 |
CD-DA |
Yes |
| MP3*2 |
Yes |
| AUDIO SYSTEM |
Output Channel |
2ch |
| Power Output-RMS |
Total Power |
120W (1kHz, 3ohms, 10% THD) |
| USB |
Slot |
Yes |
| Playback |
MP3*2 |
Yes |
| FLAC*2 |
Yes |
| USB Standard |
USB 2.0 Full Speed |
| HIGH QUALITY SOUND |
Digital Music Connection for iPod®/ iPhone®/ iPad® |
Yes |
| Full Digital Amplifier System |
Yes |
| High Performance Super Tweeter |
Yes |
| High Quality Audio Parts(Low-noise Voltage Regulator/High Quality Chip Film Capacitor) |
Yes |
| LincsD-Amp |
Yes |
| Surround |
Yes |
| Flat Front Speaker |
Yes |
| D.Bass |
Yes |
| Anti-Vibration Chassis |
yes (Main Unit) |
| Preset EQ |
4 (Heavy, Clear, Soft, Vocal) + Flat |
| Bamboo Carcoal PP Cone |
yes (Woofer) |
| Bass & Treble Control |
yes (Knob on main unit) |
| NETWORKING |
Panasonic Music Streaming App |
yes*3 |
| Wireless Audio with AirPlay® |
yes*4 |
| Bluetooth® Wireless Technology |
Yes |
| Wireless Audio with DLNA |
Yes |
| Works with iPhone 5® /iPod Touch® (5th generation) |
Yes |
| iPod®/iPhone® Connection |
yes (Integrated) |
| EASY OPERATION |
Display |
FL |
| Front |
Configuration |
3-way 3 speaker system, Bass-reflex |
| Speaker Unit [Approx.] |
Woofer: 14 cm Cone Type |
| TERMINAL |
Headphone Output |
Yes |
| Analog Audio Input - RCA |
yes (AUX) |
| Analog Audio Input - 3.5 mm (Music Port) |
- |
| TUNER |
Band/ Station Presets |
30-FM |
| Auto Tuning |
Yes |
| RDS |
Yes |
| OTHERS |
Power Supply |
AC 220-240V, 50Hz |
| Power Consumption |
Normal Use [Approx.] |
60W |
| Standby [Approx.] |
0.4W |
| Auto Power Off/ Dimmer |
yes/ yes |
| Programmable Timer |
PLAY/ SLEEP |
| DIMENSIONS, WEIGHT |
Main Unit |
Dimensions (W x H x D) [Approx.] |
210 x 120 x 266 mm |
| Weight [Approx.] |
3.1 kg |
| Front Speaker |
Dimensions (W x H x D) [Approx.] |
161 x 238 x 262 mm |
| Weight [Approx.] |
2.6 kg |
| NOTE |
*1 Playability may vary depending on the contents, discs and quality of the recording.
*2 For contents recorded disc media from CDs for your personal use.
*3 App is available on iTunes/ Google Play.
*4 To use the AirPlay function, this unit must join the same network as the compatible device.
･Specifications are subject to change without notice. Weight and dimensions are approximate. |
