| Features |
Lens Construction |
12 elements in 9 groups (1 Aspherical lens) |
| Mount |
Micro Four Thirds mount |
| Optical Image Stabilizer |
YES |
| Focal Length |
f=14mm to 45mm (35mm film camera equivalent 28mm to 90mm) |
| Aperture Type |
7 diaphragm blades / Circular aperture diaphragm |
| Aperture Range |
F3.5(Wide) - F5.6(Tele) |
| Minimum Aperture |
F22 |
| Closest Focusing Distance |
0.30m at all focal lengths |
| Maximum magnification |
Approx. 0.17x / 0.34x (35mm film camera equivalent) |
| General |
Diagonal Angle of View |
75dig(W)-27dig(T) |
| Filter Size |
φ52mm / 2.05 in |
| Max.Diameter |
φ 60mm / 2.36 in |
| Overall Length |
Approx. 60mm / 2.36 in (from the tip of the lens to the base side of the lens mount) |
| Weight [g] |
195.0 |
| Weight [oz] |
6.88 |
| Standard Accessories |
Lens Cap |
