S-48PUY6H59B

Cassette AC- Inverter, Cooling only

Features

• Active Air Purification nanoeX
• Simplistic Design
• LCD Wireless Remote Controller
• Easy Installation Design
• Operation Range up to 52°C
• Maintenance Function Time Display will show "FC" code for Air Filter Cleaning
• Active Air Purification nanoeX • Simplistic Design  • LCD Wireless Remote Controller • Easy Installation Design • Operation Range up to 52°C • Maintenance Function Time Display will show

Specs

Photo of S-48PUY6H59B

Model Indoor Unit

  • S-48PUY6H59B

Model Outdoor Unit

  • U-48PNY6H59

Panel

  • CZ-KPUB6H9

Capacity Rated

  • Cooling

    • W [Min. ~ Max.]
      • 14068 (6400-14600)
    • Btu/hr [Min. ~ Max.]
      • 48002 (21838-49817)

ISEER

  • 3.52

Star Rating

  • 3

Electrical Rating

  • Cooling

    • Running Current A [Rated ~ Max.]
      • 22~33
    • Power Input W [Min. ~ Max.]
      • 4950 (1800-5800)

Power Source

  • V/Phase/Hz

    • 230V / 1ɸ / 50Hz

Indoor Unit

  • Air Volume

    • H/M/L (CMH)
      • 2250/2100/2000
  • Sound Pressure Level

    • H/M/L dB(A)
      • 54/52/51
  • Dimension

    • Indoor LxBxH (cm)
      • 84.5 x 84.5 x 29.0
    • Panel LxBxH (cm)
      • 95.0 x 95.0 x 4.2
  • Net Weight

    • Indoor Unit / Panel (Kg)
      • 26.5/5.5

Outdoor Unit

  • Sound Pressure Level

    • dB(A)
      • 64
  • Dimension

    • LxBxH (cm)
      • 103.2 x 38.3 x 79.1
  • Net Weight

    • Kg
      • 72
  • Refrigerant Type

    • R-32

Piping Connection

  • Gas (Flare)

    • cm (inches)
      • 1.588 (5/8")
  • Liquid (Flare)

    • cm (inches)
      • 0.952 (3/8")
  • Drain

    • cm
      • 3.2

Ambient Temperature Operating Range

  • °C

    • up to 52°C

Standard Remote Controller

  • LCD Wireless Type

Compressor Type

  • Twin Rotary
