CS/CU-EU12BKY3F
MRP(Inclusive of all Taxes):₹ 53,900.00
Add to WishlistRemove from Wishlist
NO ROOM TO ADD MORE PRODUCTS
The wishlist has already reached the maximum number of products
CS/CU-EU12BKY3F
Features
ECOTough ODU Casing
The outdoor unit of Panasonic ACs is made of special "superdyma" material casing from Japanese steel that safeguards it from tough weather condition. Panasonic designs its products to be user friendly so our customers can use them for a long time with confidence. Exceptionally crafted to resist tough weather conditions like rain, direct sunlight and strong winds.
7-in-1 Convertible AC
Converti7 technology allows you to efficiently and effectively save energy with ability to adjust the AC upto 7 stages of cooling performance, through which users can manually adjust their cooling capacity ranging from 45% to more than 100% via the Converti7 button on the remote or through the MirAIe App.
Crystal Clean
Crystal Clean feature provides self-cleaning of coil through frosting and defrosting mechanisms in just 15 minutes. When your air conditioner coils become clogged with dirt and dust over a period of time, they have to work harder to push air through to cool your space. This process helps in reducing energy consumption and provide efficient cooling.
Stabilizer Free Operation
Panasonic ACs are designed to operate without constraints or limitations using stabilizer free operation with a well-defined voltage range, keeping your cooling energy efficient and optimised. If power fluctuations are beyond the defined voltage range, a stabilizer is required.
PM 0.1 Filter
Not only is outside pollution harmful to us, but indoor air quality is also equally important. To address this, Panasonic ACs come equipped with a PM 0.1 filter that is capable of providing you with clean and fresh air.
Get Inspired
Specs
Type
-
Cooling Only
Tonnage Class (TR)
-
1.0
Model [50Hz]
-
CS/CU-EU12BKY3F
Cooling Capacity Standard [Min. - Max.] (Btu/h)
-
11772 [5297 - 12949]
Cooling Capacity Standard [Min. - Max.] (W)
-
3450 [1553 - 3795]
Heating Capacity Standard [Min. - Max.] (Btu/h)
-
-
Heating Capacity Standard [Min. - Max.] (W)
-
-
ISEER
-
4.00
Annual Power Consumption (kWh)
-
667.91
Star Rating (★)
-
3★
Electrical Data
-
Voltage (V-AC)
-
230
-
-
Phase (Φ)
-
Single Phase
-
-
Running Current (A)
-
5.2
-
-
Power Input, Standard Cooling [Min. - Max.] (W)
-
1140 [348 - 1539]
-
-
Power Input, Standard Heating [Min. - Max.] (W)
-
-
-
Moisture Removal Rate (l/h)
-
1.0
Moisture Removal Rate (Pt/h)
-
2.1
Air Circulation (Indoor) (mᵌ/min)
-
14.0
Air Circulation (Indoor) (ftᵌ/min)
-
494
Net Dimensions of the Indoor Unit
-
Length (L) (cm)
-
87.0
-
-
Breadth (B) (cm)
-
22.9
-
-
Height (H) (cm)
-
29.5
-
Gross Dimensions of the Indoor Unit
-
Length (L) (cm)
-
95.2
-
-
Breadth (B) (cm)
-
28.3
-
-
Height (H) (cm)
-
37.4
-
Net Dimensions of the Outdoor Unit
-
Length (L) (cm)
-
67.2
-
-
Breadth (B) (cm)
-
24.0
-
-
Height (H) (cm)
-
52.0
-
Gross Dimensions of the Outdoor Unit
-
Length (L) (cm)
-
79.5
-
-
Breadth (B) (cm)
-
37.0
-
-
Height (H) (cm)
-
57.5
-
Noise Level
-
Indoor (H/Q) [dB-A]
-
44/32
-
-
Outdoor [dB-A]
-
53
-
Net Weight
-
IDU [ODU] (kg)
-
9 [20]
-
-
IDU [ODU] (lb)
-
19.8 [44]
-
Gross Weight
-
IDU [ODU] (kg)
-
11 [24]
-
-
IDU [ODU] (lb)
-
24.2 [53]
-
Refrigerant
-
R-32
Operating Temp. Range (℃)
-
16 ~ 55
Operating Volt. Range (V)
-
145 - 285
Refrigerant Pipe Diameter
-
Liquid Side (cm)
-
Ø0.635
-
-
Gas Side (cm)
-
Ø0.952
-
Pipe Extension
-
Chargeless Pipe Length * (m)
-
7.5
-
-
Maximum Pipe Length * (m)
-
10
-
-
Maximum Elevation Length * (m)
-
5
-
-
Additional Refrigerant Gas * (g/m)
-
10
-
Power Supply Source
-
Indoor
In the Box
-
Indoor Unit: 1N, Outdoor Unit: 1N, Remote: 1N, AAA Batteries: 2N, User Manual with Warranty Card: 1N
Note
-
1) Due to continuous research development, specifications features may change without prior notice.
2) Weight data mentioned above is provided considering tolerance of ±2kg.
