| MODEL (Indoor) |
60Hz |
CS-S9TKZW |
| Operation |
1 Unit |
| Cooling Capacity |
kJ/h |
11,520 |
| kW |
3.20 |
| Electrical Data |
Voltage |
V |
230 |
| Sound Pressure Level |
Indoor (Hi/Lo) |
(dB-A) |
44/32 |
| Moisture Removal |
L/h |
1.8 |
| Fan Output |
W |
40 |
| Air Circulation |
m³/min |
11.0 |
| (ft³/min) |
390 |
| Dimensions |
Heigt |
mm |
295 |
| Width |
mm |
919 |
| Depth |
mm |
199 |
| Net Weight |
Indoor |
kg |
9 |
| Refrigerant Pipe Diameter |
Liquid Side |
mm |
ø 6.35 |
| Gas Side |
mm |
ø 9.52 |
| Power Supply |
Outdoor |
| MODEL (Outdoor) |
60Hz |
DUAL SPLIT MODEL
CU-2S18PKZ |
| Cooling Capacity |
(min-max) |
kW |
5.00 (1.50-6.00) |
| (min-max) |
kJ/h |
18,000 (5,400-21,600) |
| EER |
kJ/Hw |
12.86 |
| Electrical Data |
Voltage |
V |
230 |
| Current |
A |
6.4 |
| Power Input (min-max) |
W |
1,400 (250-1,750) |
| Sound Pressure Level |
Outdoor |
dB(A) |
49 |
| Maximum Current |
A |
12 |
| Starting Current |
A |
6.6 |
| Compressor Output |
W |
900 |
| Fan Output |
W |
40 |
| Dimensions |
Heigt |
mm |
619 |
| Width |
mm |
824 (+70) |
| Depth |
mm |
299 |
| Net Weight |
Outdoor |
kg |
37 |
| Pipe Extension |
Chargeless Pipe Length |
m |
20 |
| Maximum Pipe Length |
1 Room |
20 |
| Total |
30 |
| Maximum Elevation Length |
m |
10 |
| Additional Refrigerant Gas* |
g/m |
15 |
| Note: |
* When pipes are not extended from standard pipe length, the required amount of refrigerant is already in the unit |
