| Feature |
• MULTI function
-Impact mode :
Impact wrench with socket
Impact driver with quick change chuck
-Drill & Driver mode :
Drill&Driver (high) with clutch function with keyless chuck Drill&Driver (low) with clutch function with keyless chuck
• Variable speed control / reversible
• LED light to support work
• With 2 battery packs, battery charger (EY0L82B57) and carrying case |
| Max.Torque |
Impact Mode |
150 N·m*1 / 130 N·m*2
*1 M16 High tensile bolt tightening for 3 sec. *2 M14 High tensile bolt tightening for 3 sec. |
| D&D Mode |
26 N·m |
| Speed at No Load |
Impact Mode |
0-2,300 min-1 (rpm) |
| D&D Mode (High) |
180-1,200 min-1 (rpm) |
| D&D mode (Low) |
60-380 min-1 (rpm) |
| Impact / min. |
Impact Mode |
3,200 ipm |
| Clutch Torque |
D&D Mode |
0.7 N·m-4.4 N·m |
| Size (LxHxW) / Weight (including battery pack) |
square drive |
210 mm x 234 mm x 61 mm / 1.85 kg |
| keyless chuck |
260 mm x 234 mm x 61 mm / 2.05 kg |
| quick change chuck |
230 mm x 234 mm x 61 mm / 1.95 kg |
| Battery Pack and Charging time (using EY0L82B57) |
14.4V / 4.2Ah (EY9L45B57)
60 minutes |
| Capacity |
DD Mode |
Holes in SPC |
t=1.6 mm, ø=21 mm |
19 pcs |
| t=1.6 mm, ø=33 mm |
16 pcs |
| Holes in Yellow Pine |
ø18 mm x 120 mm |
90 pcs |
| ø30 mm x 40 mm |
120 pcs |
| Impact Mode |
Coach Screws in Yellow Pine |
ø9 mm x 50 mm |
55 pcs |
| Self Drilling Screws in SPC |
t=2.3 mm, ø4 x 13 mm |
450 pcs |
| High Tensil Bolt |
M12 x 25 mm t=10 mm |
200 pcs |
