CS-PU24XKZ
CS-PU24XKZ
24-Hour Quality Air
Panasonic’s Standard Inverter offers both performance and better energy savings. Enjoy fast and powerful cooling sensations during start-up with a push of a button, and conveniently manage and control your air conditioning unit with the Panasonic Comfort Cloud App*.
*Requires optional network adaptor.
Specs
Size and Weight
- Height
- 295mm
- Width
- 1,040mm
- Depth
- 244mm
- Weight
- 12kg
*Please check the minimum space requirements for installation.
Manage your air conditioner using your mobile device
Powerful Mode lets you enjoy instant powerful cooling
AEROWINGS delivers faster and further airflow across the room
Balances energy savings and comfort using ECO Mode with A.I. Control
Energy savings and precise temperature control with Inverter
Basic Specification
-
Model
-
Indoor (50 Hz)
-
CS-PU24XKZ
-
-
Outdoor
-
CU-PU24XKZ
-
-
-
Cooling Capacity (min-max)
-
6.10 (1.12-7.18) kW
20,800 (3,820-24,500) Btu/h
-
-
COP (min-max)
-
3.70 (4.48-3.50) W/W
-
-
EER (min-max)
-
12.61 (15.28-11.95) Btu/hW
-
-
Weighted COP
-
4.95 W/W
-
-
Electrical Data
-
Voltage
-
220-240 V
-
-
Current
-
7.7-7.1 A
-
-
Power Input (min-max)
-
1,650 (250-2,050) W
-
-
-
Moisture Removal
-
3.4 L/h
7.2 Pt/h
-
-
Air Circulation
-
Indoor
-
19.2 m³/min (680 ft³/min)
-
-
Outdoor
-
34.9-34.9 m³/min (1,230-1,230 ft³/min)
-
-
-
Noise Level (220V-2240V)
-
Indoor (H / L / Q-Lo)
-
45/36/29 dB(A)
-
-
Outdoor (H)
-
51-51 dB(A)
-
-
-
Dimensions (Indoor)
-
Height
-
295 mm (11-5/8 inch)
-
-
Width
-
1,040 mm (40-31/32 inch)
-
-
Depth
-
244 mm (9-5/8 inch)
-
-
-
Dimensions (Outdoor)
-
Height
-
619 mm (24-3/8 inch)
-
-
Width
-
824 mm (32-15/32 inch)
-
-
Depth
-
299 mm (11-25/32 inch)
-
-
-
Net Weight
-
Indoor
-
12 kg (26 lb)
-
-
Outdoor
-
31 kg (68 lb)
-
-
-
Refrigerant Pipe Diameter
-
Liquid Side
-
ø 6.35 mm (1/4 inch)
-
-
Gas Side
-
ø 12.70 mm (1/2 inch)
-
-
-
Pipe Extension
-
Chargeless Pipe Length
-
10 m
-
-
Maximum Pipe Length
-
30 m
-
-
Maximum Elevation Length
-
20 m
-
-
Additional Refrigerant Gas*
-
15 g/m
-
-
-
Power Supply
-
Outdoor
-
Comfort Features
-
Powerful Mode
-
Yes
-
-
ECO Mode with A.I.
-
Yes
-
-
Inverter Control
-
Yes
-
-
Sleep Mode
-
Yes
-
-
Quiet Mode
-
Yes
-
-
Soft Dry Operation Mode
-
Yes
-
-
Airflow Direction Control (Up & Down)
-
Yes
-
-
Manual Horizontal Airflow Direction Control
-
Yes
-
Cleaner Air Features
-
Odour-Removing Function
-
Yes
-
-
Removable, Washable Panel
-
Yes
-
Convenience Features
-
24-Hour Dual ON & OFF Real Setting Timer
-
Yes
-
-
LCD Wireless Remote Control
-
Yes
-
-
Wireless LAN Remote Control For Internet Connection
-
Yes (Optional)
-
-
Wired Remote Control
-
Yes (Optional)
-
Reliability Features
-
Random Auto Restart
-
Yes (32 Restart Patterns)
-
-
Blue Fin Condenser
-
Yes
-
-
Long Piping (max.)
-
30 m
-
-
Top Panel Maintenance Access
-
Yes
-
-
Self-Diagnostic Function
-
Yes
-
Note
-
*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit.
Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.
