LEICA DG MACRO-ELMARIT 45mm / F2.8 ASPH. / MEGA O.I.S. (H-ES045) Micro Four Thirds Lens

H-ES045

LEICA DG MACRO-ELMARIT 45mm / F2.8 ASPH. / MEGA O.I.S.

A superior macro lens brings tiny worlds into view.
Zoom In
Zoom Out
Close
H-ES045

Specs

Photo of LEICA DG MACRO-ELMARIT 45mm / F2.8 ASPH. / MEGA O.I.S. (H-ES045) Micro Four Thirds Lens

Size and Weight

Height
63mm
Width
63mm
Depth
62.5mm
Weight
225g

Approximately. Weight excluding lens cap, lens rear cap and lens hood. Length from the tip of the lens to the base side of the lens mount.

  • Micro Four Thirds System StandardMicro Four Thirds System Standard
  • LEICA DG LensLEICA DG Lens
  • MEGA O.I.S. (Optical Image Stabilizer)MEGA O.I.S. (Optical Image Stabilizer)

Based on Leica Camera AG's strict quality standards

1:1 macro (35mm camera equivalent: 2x)

The closest focusing distance can be instantly changed to 15cm or 50cm with the switch on the lens barrel

Standard Accessories

  • Lens cap, Lens hood, Lens rear cap, Lens storage bag

Features

  • Lens Construction

    • 14 elements in 10 groups (1 aspherical lens, 1 ED lens)

  • Mount

    • Micro Four Thirds mount

  • Optical Image Stabilizer

    • Yes (MEGA O.I.S.)

  • Focal Length

    • f=45mm (35mm camera equivalent 90mm)

  • Aperture Type

    • 7 diaphragm blades / Circular aperture diaphragm

  • Aperture

    • F2.8

  • Minimum Aperture

    • F22

  • Closest Focusing Distance

    • FULL: 0.15m / 0.50ft, LIMIT: 0.5m / 1.64ft

  • Maximum magnification

    • Approx. 1.0x / 2.0x (35mm camera equivalent)

General

  • Diagonal Angle of View

    • 27°

  • Filter Size

    • φ46mm / 1.81inch

  • Max. Diameter

    • φ63mm / 2.48inch

  • Overall Length

    • Approx. 62.5mm / 2.46inch (from the tip of the lens to the base side of the lens mount)

  • Weight

    • Approx. 225g / 7.94oz
