Premium 505L Bottom Mount Refrigerator NR-BW530HVSA

Add to WishlistRemove from Wishlist

NO ROOM TO ADD MORE PRODUCTS

The wishlist has already reached the maximum number of products

505L 2-Door Bottom Freezer
NR-BW530

Fresh and Hygienic Food Storage For Healthy Eating

The PRIME+ Edition NR-BW530HVSA bottom mount fridge in Stainless Steel finish combines innovative technology with an exceptional energy rating to make the range the optimum environment to store food and drink.
  • Prime Freeze
  • Prime Fresh
  • nanoe™ X
  • Fresh Safe
Main Banner Photo of Premium Stainless Steel 2-Door Bottom Mount Refrigerator NR-BW530HVSA
Zoom In
Zoom Out
Close

Specs

Photo of Premium 505L Bottom Mount Refrigerator NR-BW530HVSA

Size and Weight

Height
1730mm
Width
750mm
Depth
750mm
Weight
91kg

*Please check the minimum space requirements for installation.

  • Prime FreezePrime Freeze
  • Prime FreezePrime Freeze
  • Prime FreezePrime Freeze
  • Prime FreshPrime Fresh
  • Prime FreshPrime Fresh
  • Prime FreshPrime Fresh
  • nanoe™ Xnanoe™ X
  • nanoe™ Xnanoe™ X
  • nanoe™ Xnanoe™ X
  • nanoe™ Xnanoe™ X
  • nanoe™ Xnanoe™ X
  • Fresh SafeFresh Safe

Capacity: Net 505 Litre (AS/NZS 4474:2018) Door Material: Steel

Prime Freeze - Rapidly seals in freshness & nutrients

Prime Fresh - Keep fish and meat fresh for longer

Fresh Safe - Keeps fruit and vegetables fresher at ideal humidity

nanoe™ X - Inhibits bacteria while deodorising

User-friendly & energy saving

SPECIFICATIONS

  • Rated Capacity (AS/NZS 4474:2018)

    • Total
      • 505 L
    • Refrigerator Compartment (PC)
      • 319 L
    • Freezer Compartment (FC)
      • 186 L
  • Product Dimensions (WxDxH)

    • 750 x 750 x 1730 mm
  • Defrost Type

    • Electric PCB Control
  • Standard / Regulation

    • AS CISPR 14.1:2020 (CISPR 14.1:2020);
      AS/NZS 60335.1:2017 (+A1,A2,A3,A4);
      AS/NZS 60335.2.24:2018 (+A1,A2); AS/NZS 4474:2018.
  • Energy Consumption

    • 320 kWh/year
  • Energy Level

    • 5 stars
  • Net Weight

    • 83 kg
  • Gross Weight

    • 91 kg
  • Voltage

    • 220 V - 240 V
  • Hertz

    • 50 Hz
  • Number of Doors

    • 2
  • Door Color

    • Matt Silver Hairlines
  • Door Material

    • Steel
  • Control Panel

    • Yes

REFRIGERATOR COMPARTMENT (PC)

  • Vegetable Storage

    • Vegetable Case (Fresh Safe)
  • Humidity Control

    • Yes
  • Foldable Shelf

    • Yes
  • Adjustable Door Pocket

    • Yes
  • Water Dispenser

    • -
  • Water Tank for Water Dispenser

    • -
  • Water Tank for Automatic Ice Maker

    • -
  • LED Light

    • Yes
  • Egg Tray

    • Yes
  • Prime Fresh Temperature Adjustable

    • Yes
  • Prime Fresh Temperature Range

    • -5ºC to 4ºC
  • nanoe™X

    • Yes
  • Ag Clean

    • Yes

FREEZER COMPARTMENT (FC)

  • Separate Storage

    • Yes (3 Cases)
  • Prime Freeze

    • Yes
  • Prime Freeze Aluminium Tray

    • Yes
  • Ice Box

    • Yes
  • Automatic Ice Maker

    • -
  • Twist Ice Tray

    • Yes
  • LED Light

    • Yes
  • Quick Freezing

    • Yes
  • Quick Ice Making

    • -
  • Power Control

    • Yes

OTHERS

  • ECONAVI

    • Yes
  • Compressor

    • Inverter
  • Refrigerant

    • R600a
  • Urethane Insulation Cyclopentane

    • Yes
  • Door Alarm

    • Yes
