| Features |
Lens Construction |
9 elements in 8 groups (2 aspherical lenses) |
| Nano Surface Coating |
- |
| Mount |
Micro Four Thirds mount |
| Optical Image Stabilizer |
Yes (MEGA O.I.S.) |
| Focal Length |
f=14-42mm (35mm camera equivalent 28-84mm) |
| Aperture Type |
7 diaphragm blades / Circular aperture diaphragm |
| Maximum Aperture |
F3.5(Wide) - F5.6(Tele) |
| Minimum Aperture |
F22 |
| Closest Focusing Distance |
0.2m/0.66ft (at focal lenghts 14-20mm) / 0.3m/0.98ft (at focal lenghts 21-42mm) |
| Maximum magnification |
Approx. 0.17x / 0.34x (35mm camera equivalent) |
| General |
Diagonal Angle of View |
75°(Wide) to 29°(TELE) |
| Filter Size |
46mm / 1.8in |
| Max. Diameter |
φ56mm / 2.2in |
| Overall Length |
Approx. 49mm / 1.9in (from the tip of the lens to the base side of the lens mount) |
| Weight |
Approx. 110g / 3.88oz (excluding lens cap, lens rear cap, and Lens hood) |
| Standard Accessories |
Lens cap, Lens hood, Lens rear cap |
