| AC power adaptor |
DC12 V/1500 mA, center pin positive |
| Battery |
Back up: UM-3 (AA size) × 2 |
| Bluetooth® |
Main battery: 14.4 V/18 V |
| Bluetooth® version |
58625 |
| Bluetooth® |
4.0˙ |
| Transmission power |
profiles A2DP/SCMS-T |
| Transmission range |
Bluetooth® specification power Class 2 (2.5 mW) |
| Supported codec SBC |
Approximately 10 m (varies according to usage conditions) |
| Compatible Bluetooth® profile |
A2DP |
| Frequency range |
FM 87.5-108 MHz (0.05 MHz/step)
AM (MW) 522-1629 kHz (9 kHz/step) |
| Tone Control |
5 Presets + Manual setting |
| Bass Control |
+3 to -5 |
| Trebel Control |
+3 to -5 |
| Loudspeaker |
3.5 inches 8 ohm × 2 |
| Output Power |
When using AC power adaptor: 1.7 W × 2
When using 14.4 V battery pack: 2.6 W × 2
When using 18 V battery pack: 4.5 W × 2 |
| Input terminal |
3.5 mm dia./Max. 2 V/stereo (AUX IN) |
| Output terminal |
USB: DC OUT 5 V/1 A
Headphone: 3.5 mm dia./3 Ω/150 mV/stereo |
| Antenna system |
FM: soft beded antenna
AM: bar antenna |
| Alarm Function |
Yes |
| Sleep Function |
Yes |
| Dimension (W × H × D) |
344 mm × 280 mm × 239 mm |
| Weight |
4.7 kg (with EY9L51)/4.0 kg (main unit only) |
| Power consumption |
Max. 7 W
0.12 W (Standby mode) |
