EY6220NQ
| DESCRIPTION | Description | Cordless Drill & Driver |
|---|---|---|
| Typical Application | Repair of appliances Production line & assembly work Circuit board assembly (of small equipment) Electrical Service engineer work Production line & assembly work | |
| Skin Only Option Available (battery and charger not included) | - | |
| POWER SUPPLY | Voltage (V) | 2.4 |
| Battery Pack Type | Ni-MH | |
| Amps (Ah) | 2.4 | |
| Charge Time (mins) | - | |
| Speed - High / Hard at No Load (rpm) | 400 | |
| Speed - Low / Soft at No Load (rpm) | 200 | |
| Speed - Impact Mode at No Load (rpm) | - | |
| Speed - Drill & Driver Mode at No Load (rpm) | - | |
| Impact - High Mode (ipm) | - | |
| Impact - Soft Mode (ipm) | - | |
| Maximum Torque - Impact Mode (Nm) | - | |
| Maximum Torque - Drill & Driver Mode (Nm) | - | |
| Maximum Torque - Stalling (Nm) | - | |
| Maximum Torque - Instant (Nm) | - | |
| Maximum Torque - High (Nm) | 1.5 | |
| Maximum Torque - Medium (Nm) | - | |
| Maximum Torque - Low (Nm) | 2.9 | |
| Ejection Pressure (kgf) | - | |
| Capacity (ml) | - | |
| FEATURES | Tough Tool - IP56 Approval | - |
| Safety Switch Lock | - | |
| Clutch Stages | Multi-stage clutch plus drill | |
| Electric Brake | - | |
| Chuck Type | 6.5mm Hex quick connect | |
| No of Speeds | 2 | |
| Variable Speed Control / Reversible | - | |
| Slow Start Switch | - | |
| LED Light | - | |
| Ergonomic Design | Yes | |
| Additional Design Features | Auto shut off clutch | |
| FEATURES - DRILL amp DRIVER | Maximum Drill Diameter - Wood (mm) | - |
| Maximum Drill Diameter - Metal (mm) | - | |
| Maximum Drill Diameter - Concrete (mm) | - | |
| Maximum Holesaw (mm) | - | |
| Maximum Screws Driving - Wood (mm) | - | |
| Maximum Screws Driving - Self-Drilling Screw (mm) | - | |
| Maximum Screws Driving - Machine Screw (mm) | - | |
| FEATURES - HAMMERING | Hammering Force - Soft Mode (kN) | - |
| Hammering Force - Hard Mode (kN) | - | |
| Blows Per Minute - Hard Mode | - | |
| Blows Per Minute - Soft Mode | - | |
| FEATURES - GRINDING amp CUTTING | Grinding Wheel Diameter (mm) | - |
| Blade Diameter (mm) | - | |
| Maximum Cutting Depth (mm) | - | |
| Stroke Per Minute at No Load | - | |
| Stroke Length (mm) | - | |
| Cutting Performance - Wood (mm) | - | |
| Cutting Performance - Mild Steel (mm) | - | |
| Cutting Performance - Aluminium (mm) | - | |
| GENERAL | Dimensions - L x H x W (mm) | 238 x 127 x 36 |
| Weight (kg) | 0.43 | |
| ACCESSORIES | Standard | 2.4V Battery Pack (2.8 Ah Ni-MH Battery Type N) EY9221B57 Charger for Li-ion, Ni-MH Battery EY0L11B57 |
| Optional | - |
