PM-EB8ULFC-W
8MP Fixed Bullet IP Camera
Features
Key Features
• 8MP Fixed Bullet Network camera
• 120dB Wide Dynamic Range
• Color Night Vision: Color: 0.01 lux @F1.6, AGC ON
• 20~30m IR night view distance; 20~30m white light view distance
• IP67 protection from dust and water
• Advanced encryption and access control
• NDAA
4K Resolution
IP67 Weatherproof
True WDR Technology
Superior Night Vision
Mobile App Access
Specs
8MP Fixed Bullet Network camera
120dB Wide Dynamic Range
Color Night Vision: Color: 0.01 lux @F1.6, AGC ON
20~30m IR night view distance
20~30m white light view distance
IP67 protection from dust and water
CAMERA
-
Type
-
8MP Fixed Bullet Network Camera
-
-
Image Sensor
-
1/2.7" CMOS
-
-
Max Resolution
-
8MP (3840×2160)
-
-
Electronic Shutter
-
1/3s~1/100000 s
-
-
Min. Illumination
-
Color: 0.01 lux @F1.6, AGC ON
-
-
IR Distance / Light Range
-
20~30m IR night view distance
20~30m white light view distance
-
Lens
-
Focal length
-
2.8mm@F1.6
-
-
Focus
-
Fixed
-
-
Iris Type
-
Fixed Iris
-
-
Optical zoom
-
No
-
-
Lens Mount
-
M12
-
-
Angular Field of View
-
H.FoV: 106.5°
V.FoV: 58.5°
D.FoV: 124°
-
-
Day & Night
-
ICR
-
-
Video Compression
-
Mainstream: H.265+/H.265/H.264+/H.264
Sub stream: H.265+/H.265/H.264+/H.264/MJPEG
-
-
Supported Resolution
-
8MP (3840×2160)
6MP (3200×1800)
4MP (2688×1520)
2K (2560×1440)
1080P (1920×1080)
720P (1280×720)
D1(704×480)
VGA (640×480)
640×360, 480×240
CIF(352×288)
-
-
Number of Supported Stream
-
2
-
-
Mainstream
-
60Hz: 8MP/6MP/4MP/2K/1080P (1~20fps)
50Hz: 8MP/6MP/4MP/2K/1080P (1~20fps)
-
-
Sub Stream
-
60Hz: 720P/D1/VGA/640×360/480×240/CIF (1~20fps)
50Hz: 720P/D1/VGA/640×360/480×240/CIF (1~20fps)
-
-
Third Stream
-
-
-
-
Bit Rate
-
64 Kbps~10Mbps
-
-
Bit Rate Type
-
VBR/CBR
-
-
Image Settings
-
ROI
Saturation
Brightness
Hue
Contrast
Wide Dynamic
Sharpness
Image Mirror
Image Flip
NR
etc. adjustable through client software or web browser
-
-
Audio Compression
-
G711A/U
-
-
Region Of Interest
-
Each ROI to be configured separately
-
Operational
-
Wide Dynamic Range(WDR)
-
120dB
-
-
Back Light Compensation (BLC)
-
Yes
-
-
High Light Compensation (HLC)
-
Yes
-
-
Defog
-
-
-
-
Digital Noise Reduction (DNR)
-
Yes
-
-
S/N ratio
-
≥50dB
-
-
Angle Adjustment
-
Pan: 0°~360°
Tilt: 0°~80°
Rotation: 0°~360°
-
INTERFACES
-
Network
-
RJ 45 10M/100M self-adaptive Ethernet port
-
-
Video
-
-
-
-
Audio
-
1CH audio input
1CH built-in MIC
-
-
Storage
-
Built-in micro SD card slot, up to 256GB
-
-
Alarm
-
-
-
-
RS485
-
-
-
DORI DISTANCE
-
Lens
-
2.8mm
-
-
Detect
-
77m(253ft)
-
-
Observe
-
31m(101ft)
-
-
Recognize
-
15m(51ft)
-
-
Identify
-
8m(25ft)
-
INTELLIGENT ANALYTICS
-
Statistics
-
-
-
-
Audio Exception Detection
-
-
-
-
Face Detection
-
-
-
-
Video Metadata(Human/Vehicle Attributes / Two Wheelers)
-
-
-
Other Analytics
-
Motion Detection
-
Support smart motion detection
Filtering motion alarm triggered by other target types except humans.
-
-
Smart Alarm
-
Motion detection
SD card full, SD card error
IP address conflict
Network disconnection
White light alarm triggered by smart events
-
-
Smart Event
-
(Human) region intrusion detection
(Human) line crossing detection
-
FUNCTIONS
-
Remote Monitoring
-
Web browser
NVR
Panasonic VMS 2.X
Mobile APP
-
-
Web Browser
-
Chrome 89.0+
Edge 89.0+
Firefox 87.0+
Safari 14.0+
-
-
Online Connection
-
Support simultaneous monitoring for up to 6 users;
Support multi-stream real time transmission
-
-
Network Protocol
-
UDP, IPv4, IPv6, DHCP, NTP, RTSP, DDNS, 802.1x
HTTP, P2P, QoS
-
-
Interface Protocol
-
ONVIF Profile S/G/M
-
-
Other Functions
-
Watermark
IP Address Filtering
Video Mask
Heartbeat
Smart Supplement Light
ANR
Disarming
-
-
Security
-
Video encryption
Firmware encryption
Configuration encryption
Illegal login lock
IP address filtering
802.1x authentication
Basic and digest authentication for HTTP/RTSP
NDAA
-
General
-
Power Supply
-
DC12V/PoE
-
-
PoE
-
Yes, IEEE802.3af
-
-
Power Consumption
-
< 7W
-
-
Weather Protection
-
IP67 protection from dust and water
-
-
Operating Environment
-
-30°C~60°C (-22°F~140°F)
Humidity: less than 95% (non-condensing)
-
-
Storage Environment
-
-30°C~65°C (-22°F~149°F)
Humidity: less than 95% (non-condensing)
-
-
Dimensions (mm)
-
167.6×75×74.6
-
-
Weight (net)
-
Approx.0.416KG
-
-
Installation
-
Ceiling mounting
Wall mounting
-
-
Certificate
-
EMC:EN 55032:2015+A11:2020 EN 55035:2017+A11:2020
Safety: EN IEC 62368-1:2020+A11:2020
RoHS:2011/65/EU
-
-
Footnote / Disclaimer
-
Disclaimer: Panasonic accepts no responsibility or liability for the performance of the network, nor for any third-party products used in conjunction with this system.
Product dimensions and masses are approximate. Specifications are subject to change without notice.
-
