|Metrics||Dimensions (W x H x D)||112.0 x 68.8 x 41.6 mm (4.41 x 2.71 x 1.64 inch)|
|Weight||Approx. 328 g with Battery and SD Memory Card (0.72 lb)|
Approx. 286 g without Battery and SD Memory Card (0.63 lb)
|Optics||Pixels||Camera Effective Pixels||20.3 Megapixels|
|Sensor||Sensor Size / Total Pixels / Filter||1/2.3-inch High Sensitivity MOS Sensor / 21.1 Total Megapixels / Primary Color Filter|
|Lens||Aperture||F3.3 - 6.4 / Multistage Iris Diaphragm (F3.3 - 8.0 (W), F6.4 - 8.0 (T))|
|Focal Length||f = 4.3 - 129mm|
(24 - 720mm in 35mm equiv. in 4:3)
(25 - 750mm in 35mm equiv. in 3:2)
(26 - 780mm in 35mm equiv. in 16:9)
(28 - 840mm in 35mm equiv. in 1:1)
(35 - 1050mm in 35mm equiv. in 4K PHOTO recording)
(35 - 1050mm in 35mm equiv. in 4K video recording)
(26 - 780mm in 35mm equiv. in 16:9 video recording / O.I.S. Off / Level Shot function Off)
(28 - 840mm in 35mm equiv. in 16:9 video recording / O.I.S. On / Level Shot function Off)
(30 - 900mm in 35mm equiv. in 16:9 video recording / O.I.S. On / Level Shot function On)
|Extra Optical Zoom (EZ)||41.8x (4:3 / 10M (M)), 59.2x (4:3 / 5M (S))|
|Lens||LEICA DC VARIO-ELMAR|
12 elements in 9 groups
(5 aspherical lenses / 10 aspherical surfaces)
|Optical Image Stabilizer||5-Axis HYBRID O.I.S. +*|
*5-Axis compensation works in video recording except for 4K video or high-speed video recording.
|Digital Zoom||Max. 4x (When Digital Zoom is used simultaneously with Intelligent Zoom, you can only increase the zoom ratio up to 2x.)|
|Focus||Focusing Area||Normal: Wide 50 cm - infinity / Tele 200 cm - infinity AF Macro / MF / Intelligent Auto / Motion Picture: Wide 3 cm - infinity / Tele 200 cm - infinity|
|AF Assist Lamp||Yes (On / Off)|
|Focus||AF / AF Macro / Macro Zoom * Each available with AFS (Single) / AFF (Flexible) / AFC (Continuous) Quick AF, Continuous AF (during motion picture recording), Touch AF/AE Function, Touch Shutter, Eye Sensor AF, Touch Pad AF, MF Assist, Touch MF Assist, AF+MF, Focus Peaking, One Shot AF (Set the Fn button in custom menu to AF-ON), Low Light AF|
|Shutter||Shutter Speed [Still Image]||Still Image:|
Approx. 4 - 1/2,000 sec (Mechanical Shutter)
Approx. 1 - 1/16,000 sec (Electronic Shutter)
Artistic Nightscape (Approx. 30 sec)
|Shutter Speed [Motion Picture]||Motion Picture:|
Approx. 1/25 - 1/16,000 sec
Approx. 1/2 - 1/16,000 sec (Creative Video M Mode / MF Mode)
|Recording||File||File Format||Still Image: JPEG (DCF/Exif2.31), RAW|
4K PHOTO: MP4
Motion Picture: AVCHD Progressive, AVCHD (Audio format: Dolby Audio 2ch), MP4 (Audio format: AAC 2ch)
|Recording Modes||Recording Mode||Intelligent Auto, P, A, S, M, Creative Video, C (Custom), Panorama Shot, Scene Guide, Creative Control|
|Filter||Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome* / Silky Monochrome* / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Soft Focus* / Fantasy / Star Filter* / One Point Color / Sunshine* (22 filters) *For photos only.|
|Scene Guide||Clear Portrait, Silky Skin, Backlit Softness, Clear in Backlight, Relaxing Tone, Sweet Child's Face, Distinct Scenery, Bright Blue Sky, Romantic Sunset Glow, Vivid Sunset Glow, Glistening Water*, Clear Nightscape, Cool Night Sky, Warm Glowing Nightscape, Artistic Nightscape, Glittering Illuminations*, Handheld Night Shot, Clear Night Portrait, Soft Image of a Flower*, Appetizing Food, Cute Dessert, Freeze Animal Motion, Clear Sports Shot, Monochrome *For photos only.|
|Burst Shooting Mode (Approx.)||[AFS] H: 10 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View)|
[AFC] H: 5 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View)
|4K Photo Mode (*2)||4K Burst: 30 frames/sec, max. 15 min|
4K Burst (S/S): 30 frames/sec, max. 15 min
4K Pre-Burst: 30 frames/sec, approx. 2 sec
Exif Information: Yes (Each JPEG image cropped out of the 4K burst file complies with EXIF.)
Auto Marking Function: Auto / Face Priority / Motion Priority (in 4K Burst mode and 4K Burst (S/S) mode)
|Motion Picture Recording (*2)||MP4||[4K]3840x2160 4K/30p: 100Mbps|
[4K]3840x2160 4K/25p: 100Mbps
[FHD]1920x1080 FHD/60p: 28Mbps
[FHD]1920x1080 FHD/50p: 28Mbps
[FHD]1920x1080 FHD/30p: 20Mbps
[FHD]1920x1080 FHD/25p: 20Mbps
[HD]1280x720 HD/30p: 10Mbps
[HD]1280x720 HD/25p: 10Mbps
|AVCHD||[FHD]1920x1080 FHD/50p: 28Mbps, 50p recording|
[FHD]1920x1080 FHD/50i: 17Mbps, 50i recording
[FHD]1920x1080 FHD/25p: 24Mbps, 50i recording (sensor output is 25fps)
|High Speed Video(*2) MP4||[HD]1280x720 HD/30p (Sensor Output is 120fps)|
[HD]1280x720 HD/25p (Sensor Output is 100fps)
[VGA]640x480 VGA/30p (Sensor Output is 240fps)
[VGA]640x480 VGA/25p (Sensor Output is 200fps)
|Continuous Recordable Time (Motion Pictures) (*2)||MP4||4K/30p, 4K/25p: Approx. 90 min (rear monitor), 80 min (LVF) FHD/60p, FHD/50p: Approx. 100 min (rear monitor), 90 min (LVF)|
|AVCHD||FHD/50p: Approx. 100 min (rear monitor), 90 min (LVF)|
FHD/50i: Approx. 100 min (rear monitor), 100 min (LVF)
|Actual recordable Time (Motion Pictures) (*2)||MP4||4K/30p, 4K/25p: Approx. 45 min (rear monitor), 40 min (LVF) FHD/60p, FHD/50p: Approx. 50 min (rear monitor), 45 min (LVF)|
|AVCHD||FHD/50p: Approx. 50 min (rear monitor), 45 min (LVF)|
FHD/50i: Approx. 50 min (rear monitor), 50 min (LVF)
|Exposure Parameters||Exposure||Program AE, Aperture Priority AE, Shutter Priority AE, Manual|
|Exposure Compensation||1/3 EV step, +/-5 EV (+/-3 EV for motion picture / 4K PHOTO)|
|Light Metering||Intelligent Multiple / Center Weighted / Spot|
|ISO Sensitivity||Still Image: Auto / i.ISO / 80 / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 (Extended ISO) Motion Picture: Auto / 80 / 100 / 200 / 400 / 800 / 1600 / 3200 (Changeable to 1/3 EV step)|
|Picture Quality||Still Picture Recording||4:3 5184x3888 (20M) (L) / 3712x2784 (10M) (M) / 2624x1968 (5M) (S)|
3:2 5184x3456 (17M) (L) / 3712x2480 (9M) (M) / 2624x1752 (4.5M) (S)
16:9 5184x2920 (14.5M) (L) / 3840x2160 (8M) (M) / 1920x1080 (2M) (S)
1:1 3888x3888 (14.5M) (L) / 2784x2784 (7.5M) (M) / 1968x1968 (3.5M) (S)
|Image Quality||RAW / RAW+Fine / RAW+Standard / Fine / Standard|
|White Balance||AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Color Temperature Setting|
|Photo Style||Standard, Vivid, Natural, Monochrome, Scenery, Portrait, Custom|
|Picture Adjustment||Contrast, Sharpness, Noise Reduction, Saturation*, Color Tone**, Filter Effect**|
*Except for Monochrome mode. **For Monochrome mode only.
|Bracket||AE Bracket||3, 5, 7 images in 1/3, 2/3 or 1 EV step, Max. +/-3 EV|
|White Balance Bracket||3 images in blue/amber axis or in magenta/green axis|
|Other||Digital Red Eye Correction (Red-Eye Removal)||Yes (On / Off)|
2412 MHz - 2462 MHz (1-11 ch)
WPA / WPA2
Infrastructure Mode / WPS
|Bluetooth||Bluetooth® v4.2 (Bluetooth Low Energy (BLE))|
|Self Timer||2 sec / 10 sec / 10 sec (3 images)|
|Self Shot||Self Shot Mode||Yes (Single, Self timer: 1, 2, 3 or 4 images, 4K PHOTO, Panorama)|
|Shutter||Shutter Button, Touch, Face Shutter, Buddy Shutter|
|Effect||Soft Skin: 10 levels, Filter Select: Expressive / Retro / High Key / Monochrome / Toy Effect, Background Control: Defocus / Clear, Slimming Mode: 10 levels|
|Playback||Display||Playback Mode||All, Picture Only, Video Only, Slideshow (All / Picture Only / Video Only, duration & effect is selectable), Calendar|
|Thumbnails / Zoomed Playback||12,30-thumbnails / Yes|
|Rating / Rotate Image / Protect||Yes / Yes / Yes|
|Show Histogram/ Show Highlights||Yes / Yes|
|Edit||Retouch||Clear Retouch, Beauty Retouch|
|Image Composition||Light Composition, Sequence Composition|
|Creating a Motion Picture from Still Pictures||Time Lapse Video, Stop Motion Video|
|Resize/ Cropping||Yes / Yes|
|Title Edit / Text Stamp||Yes / Yes|
|Setup||OSD language||English, Chinese (Traditional), Chinese (Simplified), Thai, Arabic, Persian, Vietnamese, Hindi|
|Others||Finder||Viewfinder||0.21" LVF (Live View Finder) (2,330k dots equiv.), Field of View: Approx. 100%|
Magnification: Approx.0.53x (35 mm camera equivalent)
|Monitor||LCD Monitor||3.0" (7.5cm) TFT Screen LCD Display (1040k dots), Tiltable monitor|
Static Touch Control
Field of View: Approx. 100%, AF Coating
|Flash||Built- in- Flash||Auto*, Auto/Red-eye Reduction*, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off *For iA, iA+ mode only.|
0.6 - 5.6m (Wide / ISO Auto), 2.0 - 2.9m (Tele / ISO Auto)
|Media||Recording Media||SD Memory Card, SDHC Memory Card, SDXC Memory Card (Compatible with UHS-I UHS Speed Class 3 standard SDHC / SDXC Memory Cards)|
|Audio||Microphone / Speaker||Stereo / Mono|
|Interface||Interface||microHDMI typeD (*3), USB2.0 Micro-B|
|Power||Power||Li-ion Battery Pack (7.2V, 1025mAh, 7.4 Wh) (Included) USB power charging|
|Battery life (Approx.)||Approx. 380 images (rear monitor), 250 images (LVF), 340 images (LVF eco30fps setting) (*1)|
|Standard Package||Included Software||・ The software to edit and playback images on computer is not bundled with this camera. To do this, PHOTOfunSTUDIO is available for download at Panasonic website using computer connected to the Internet.|
http://panasonic.jp/support/global/cs/soft/download/d_pfs10ae.html (For Windows)
・ The software to process RAW file on computer is not bundled with this camera. To do this, SILKYPIX Developer Studio is available for download at Ichikawa Soft Laboratory's website using computer connected to the Internet.
http://www.isl.co.jp/SILKYPIX/english/p/ (For Windows / Mac)
|Standard Accessories||Battery Pack, AC Adaptor, USB Cable, Hand Strap|
・ Operating Instructions for advanced features is available for downloaded at Panasonic LUMIX Customer Support Site using PC, smartphone or tablet connected to the Internet.
|NOTE||*1 Recording conditions by CIPA standard|
- Temperature: 23 oC (73.4 oF) / Humidity: 50%RH when monitor is on.
- Using a Panasonic SDHC Memory Card
- Using the supplied battery.
- Starting recording 30 seconds after the camera is turned on. (When the optical image stabilizer function is set to [ON].)
- Recording once every 30 seconds with full flash every second recording.
- Rotating the zoom lever from Tele to Wide or vice versa in every recording.
- The number of recordable pictures varies depending on the recording interval time.
- If the recording interval time becomes longer, the number of recordable pictures decreases.
- CIPA is an abbreviation of [Camera & Imaging Products Association].
*2 - Use a card with SD Speed Class with ""Class 4"" or higher when recording motion pictures.
- Use a card with SD Speed Class with ""UHS-I Speed Class 3 (U3)"" when recording motion pictures with [MP4] in [4K] or [4K PHOTO].
(SD speed class is the speed standard regarding continuous writing.)
- Recording stops when the continuous recording time exceeds 29 minutes and 59 seconds with [AVCHD].
- Recording stops when the continuous recording time exceeds 15 minutes with [MP4] in [4K].
- When using an SDHC memory card: You can continue recording without interruption even if the file size exceeds 4 GB, but the motion picture file will be divided and recorded/played back separately.
- When using an SDXC memory card: You can record a motion picture in a single file.
- Recording stops when the continuous recording time exceeds 29 minutes and 59 seconds with [MP4] in [FHD] [HD] and [High Speed Video].
You can continue recording without interruption even if the file size exceeds 4 GB, but the motion picture file will be divided and recorded/played back separately.
- These are standard times taken at a temperature of 23 oC (73.4 oF) and a humidity of 50%RH.
- The time available for recording varies depending on the environment, the interval between recordings, and the manner of use.
- Actual recordable time is the time available for recording when repeating actions such as switching the power supply [ON] / [OFF], starting/stopping recording, zoom operation etc.
*3 For [4K] video output, use an HDMI cable that has the HDMI logo on it, and that is described as"4K compatible".
