LEICA DG MACRO-ELMARIT 45mm / F2.8 ASPH. / MEGA O.I.S. (H-ES045) Micro Four Thirds Lens

Add to WishlistRemove from Wishlist

NO ROOM TO ADD MORE PRODUCTS

The wishlist has already reached the maximum number of products

H-ES045

LEICA DG MACRO-ELMARIT 45mm / F2.8 ASPH. / MEGA O.I.S.

A superior macro lens brings tiny worlds into view.
Zoom In
Zoom Out
Close

Features

LEICA DG Lens – ultimate optics

Opt for a LEICA DG lens and get the ultimate in optical quality and performance. They naturally meet the strict quality standards set by Leica Camera AG. Thanks to the sophisticated design of these lenses, you will enjoy brilliant clarity all the way to the edges of your photos. At the same time, distortions of all kind are prevented to enable precise, sharp picture rendering. This means you have the ideal tool for pro-level images in the palm of your hand.
・Leica is a registered trademark of Leica Microsystems IR GmbH.
LEICA DG Lens – ultimate optics

More-than-macro lens

This LEICA DG MACRO-ELMARIT lens lets you do much more than just make small things bigger. Not limited to beautiful soft focusing, it lets you bring the entire frame – from corner to corner – into sharp focus. That gives you the freedom to create a wide variety of compositions, from landscapes to portraits. The inner focus system ensures excellent results – making this LEICA lens a true all-around performer.
More-than-macro lens

O.I.S. for ultra-sharp photos

Capture what you see on the spur of the moment. Optical image stabilization (O.I.S.) technology built directly into the lens ensures your photos will look great, with sharp, blur-free contours across the entire image.
O.I.S. for ultra-sharp photos

H-ES045 lens construction

The optimized configuration has 14 elements in 10 groups, including 1 ASPH and 1 ED lenses to minimize aberrations and ensure superb resolution.
H-ES045 lens construction

H-ES045 MTF chart

They meet the strict optical standards set by Leica Camera AG and offer outstanding sharpness and resolution from the center to the edges of the frame. Demonstrates uncompromising expressiveness.
・For lenses that are capable of compensating distortion, the horizontal axis shows the distance from the center of the corrected image.
H-ES045 MTF chart

Get Inspired

Specs

Photo of LEICA DG MACRO-ELMARIT 45mm / F2.8 ASPH. / MEGA O.I.S. (H-ES045) Micro Four Thirds Lens

Size and Weight

Height
63mm
Width
63mm
Depth
62.5mm
Weight
225g

Approximately. Weight excluding lens cap, lens rear cap and lens hood. Length from the tip of the lens to the base side of the lens mount.

  • Micro Four Thirds System StandardMicro Four Thirds System Standard
  • LEICA DG LensLEICA DG Lens
  • MEGA O.I.S. (Optical Image Stabilizer)MEGA O.I.S. (Optical Image Stabilizer)

Based on Leica Camera AG's strict quality standards

1:1 macro (35mm camera equivalent: 2x)

The closest focusing distance can be instantly changed to 15cm or 50cm with the switch on the lens barrel

Standard Accessories

  • Lens cap, Lens hood, Lens rear cap, Lens storage bag

Features

  • Lens Construction

    • 14 elements in 10 groups (1 aspherical lens, 1 ED lens)
  • Mount

    • Micro Four Thirds mount
  • Optical Image Stabilizer

    • Yes (MEGA O.I.S.)
  • Focal Length

    • f=45mm (35mm camera equivalent 90mm)
  • Aperture Type

    • 7 diaphragm blades / Circular aperture diaphragm
  • Aperture

    • F2.8
  • Minimum Aperture

    • F22
  • Closest Focusing Distance

    • FULL: 0.15m / 0.50ft, LIMIT: 0.5m / 1.64ft
  • Maximum magnification

    • Approx. 1.0x / 2.0x (35mm camera equivalent)

General

  • Diagonal Angle of View

    • 27°
  • Filter Size

    • φ46mm / 1.81inch
  • Max. Diameter

    • φ63mm / 2.48inch
  • Overall Length

    • Approx. 62.5mm / 2.46inch (from the tip of the lens to the base side of the lens mount)
  • Weight

    • Approx. 225g / 7.94oz
