Model (50Hz) |
CS-UA24RKD [CU-UA24RKD] |
Cooling/Heating Capacity |
Btu/h |
21000/21000 21200/21200 |
kW |
6.15/6.15 6.21/6.21 |
EER |
Btu/hW |
9.29/9.25 10.39/9.77 |
COP |
W/W |
2.75/2.74 3.04/2.86 |
Electrical Data |
Voltage |
V |
220V/240V |
Running Current |
A |
10.10/9.73 9.10/9.38 |
Power Input |
W |
2260/2270 2040/2170 |
Air Circulation (Indoor/Hi) |
m³/min. |
18.7 18.7 |
ft³/min. |
660 660 |
Moisture Removal |
L/h |
3.4 |
Pt/h |
7.2 |
Dimensions |
Height |
mm |
290 [619] |
Width |
mm |
1070 [824] |
Depth |
mm |
220 [299] |
Noise Level |
Indoor [H/L/Q-Lo] |
[dB-A] |
52/42 |
Outdoor |
[dB-A] |
[64] |
Net Weight |
kg |
12 [43] |
lb |
26 [95] |
Refrigerant Pipe Diameter |
Liquid Side |
mm |
Ø6.35 |
inch |
1/4" |
Gas Side |
mm |
Ø15.88 |
inch |
5/8" |
Pipe Extension |
Chargeless Pipe Length |
m |
7.5 |
Maximum Pipe Length |
m |
15 |
Additional Refrigerant Gas* |
g/m |
30 |
Power Supply |
Indoor |
NOTE |
* When pipes are not extended from the standard pipe length, the required amount of refrigerant is already in the unit. |
