CS/CU-PN30XKH-1

24-Hour Quality Air

Panasonic’s Standard Non-Inverter with high cooling capacity cools large spaces so you can be comfortable wherever you are in the room. Enjoy fast and powerful cooling with a single press of the POWERFUL button while AEROWINGS gives you further airflow for optimal cooling.
Zoom In
Zoom Out
Close

Features

Instant Cooling with A Push of A Button

POWERFUL Mode cools your room faster by running both the compressor and indoor fan at super high speed for you to enjoy instant powerful cooling during start-up.
Instant Cooling with A Push of A Button

Stay Cool with Faster, Further Airflow

AEROWINGS concentrates cool air for further and faster airflow across the room using 2 flaps. The sub-flap compresses and concentrates cool air, while the outer flap helps to deliver further airflow.
Stay Cool with Faster, Further Airflow

Eco-friendly R32 Refrigerant

Panasonic air conditioners have been increasingly adopting the eco-friendly R32 refrigerant. An excellent heat transfer medium with a higher cooling capacity, this refrigerant reduces energy costs. It also has low global warming potential, making it friendlier to the environment.
Eco-friendly R32 Refrigerant

High Cooling Capacity for Large Spaces

Its 3.0HP high cooling capacity is ideal for cooling large spaces such as large living room area, Small Office Home Office (SOHO) and light commercial spaces.
High Cooling Capacity for Large Spaces

Specs

Photo of CS/CU-PN30XKH-1

Size and Weight

Height
309mm
Width
1,212mm
Depth
269mm
Weight
16kg

*Please check the minimum space requirements for installation.

High cooling capacity for large rooms

POWERFUL Mode lets you enjoy instant powerful cooling

AEROWINGS delivers faster and further airflow across the room

Eco-friendly R32 refrigerant provides greater energy and cost-effectiveness at low environmental impact

Basic Specification

  • Model

    • Indoor (50 Hz)
      • CS-PN30XKH-1
    • Outdoor
      • CU-PN30XKH-1
  • Cooling Capacity

    • 8.80 kW
      30,000 Btu/h
  • EER

    • 12.40 Btu/hW
      3.64 W/W
  • Electrical Data

    • Voltage
      • 230 V
    • Current
      • 10.6 A
    • Power Input
      • 2,420 W
  • Moisture Removal

    • 5.0 L/h
      10.6 Pt/h
  • Air Circulation

    • Indoor
      • 25.5 m³/min (900 ft³/min)
    • Outdoor
      • 54.4 m³/min (1,920 ft³/min)
  • Noise Level

    • Indoor (H / L)
      • 51/46 dB(A)
    • Outdoor (H)
      • 56 dB(A)
  • Dimensions (Indoor)

    • Height
      • 309 mm (12-3/16 inch)
    • Width
      • 1,212 mm (47-23/32 inch)
    • Depth
      • 269 mm (10-19/32 inch)
  • Dimensions (Outdoor)

    • Height
      • 695 mm (27-3/8 inch)
    • Width
      • 875 mm (34-15/32 inch)
    • Depth
      • 320 mm (12-5/8 inch)
  • Net Weight

    • Indoor
      • 16 kg (35 lb)
    • Outdoor
      • 53 kg (117 lb)
  • Refrigerant Pipe Diameter

    • Liquid Side
      • ø 6.35 mm (1/4 inch)
    • Gas Side
      • ø 15.88 mm (5/8 inch)
  • Pipe Extension

    • Chargeless Pipe Length
      • 7.5 m
    • Maximum Pipe Length
      • 40 m
    • Maximum Elevation Length
      • 30 m
    • Additional Refrigerant Gas*
      • 25 g/m
  • Power Supply

    • Outdoor

Comfort Features

  • Sleep Mode

    • Yes
  • Powerful Mode

    • Yes
  • Soft Dry Operation Mode

    • Yes
  • Quiet Mode

    • Yes
  • Airflow Direction Control (Up & Down)

    • Yes
  • Manual Horizontal Airflow Direction Control

    • Yes

Cleaner Air Features

  • Odour Removing Function

    • Yes
  • Removable Washable Panel

    • Yes

Convenience Features

  • 24-Hour ON & OFF Real Setting Timer

    • Yes
  • LCD Wireless Remote Control

    • Yes
  • Wired Remote Control

    • Yes (Optional)

Reliability Features

  • Random Auto Restart

    • Yes (32 Restart Patterns)
  • Blue Fin Condenser

    • Yes
  • Long Piping (max.)

    • 40 m
  • Top Panel Maintenance Access

    • Yes

Note

  • *When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit.
    Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.
