General Information | Indoor Model Number | CS-SC12MKH | |
---|---|---|---|
Outdoor Model Number | CU-PC12MKH | ||
Btu/h | 12,000 | ||
kW | 3.51 | ||
EER [Btu/hW] | L/h | 2.0 | |
Pt/h | 4.2 | ||
Air Circulation (Indoor/Hi) | m3/min | 11.1 | |
ft3/min | 392 | ||
Product Dimensions | Dimension H X W X D mm | (indoor) | 290 X 870 X 204 |
(Outdoor) | 510 X 650 X 230 | ||
Product Weight | Net Weight kg | (Indoor) | 9 |
(Outdoor) | 25 | ||
Technical Features | Liquid Side mm (inch) | 6.35 (1/4) | |
Gas Side mm (inch) | 12.70 (1/2) | ||
Power Supply | Indoor | ||
Comfortable Features | ADVANCED+PLUS e-ion Air Purifying System | No | |
Patrol Sensor | No | ||
SUPER Alleru-Buster Filter | Yes (Optional) | ||
Odour-Removing Function | Yes | ||
Removable, Washable Panel | Yes | ||
Catechin Air Purifying Filter | No | ||
Solar Refreshing Deodorizing Filter | No | ||
Inverter Control | No | ||
ECO Patrol | No | ||
Mild Dry Cooling | No | ||
Quiet Mode | No | ||
Powerful Mode | No | ||
Soft Dry Operation Mode | No | ||
Wide Long Airflow Vane | Yes | ||
Personal Airflow Creation | No | ||
Airflow Direction Control (Up Down) | Yes | ||
Manual Airflow Direction Control (Left Right) | No | ||
Manual Horizontal Airflow Direction Control | Yes | ||
Sleep Mode Auto-Control | No | ||
Automatic Operation Mode (Cooling) | No | ||
Convenient Features | 24-Hour Dual ONOFF Real Setting Timer | No | |
24-Hour ONOFF Real Setting Timer | No | ||
12-Hour ONOFF Setting Timer | No | ||
LCD Wireless Remote Controller | No | ||
Wired Remote Controller | Yes | ||
Reliable Features | Auto Restart | No | |
Random Auto Restart (32 Restart Patterns) | Yes | ||
Blue Fin Condenser | Yes | ||
Long Piping | 15m | ||
Top-Panel Maintenance Access | Yes | ||
Self-Diagnostic Function | No | ||
Electricity | Rated Voltage | 230V | |
Running Current | 6.0A | ||
Power Input | 1,190W | ||
NOTE | Design and specifications are subject to change without notice. |
