S-18PUB5H59B

Cassette AC Non-Inverter, Cooling only

Features

• Simplistic Design
• LCD Wireless Remote Controller
• Easy Installation Design
• Operation Range up to 50°C
• Maintenance Function Time Display will show "FC" code for Air Filter Cleaning
• Simplistic Design  • LCD Wireless Remote Controller • Easy Installation Design • Operation Range up to 50°C • Maintenance Function Time Display will show

Specs

Photo of S-18PUB5H59B

Model Indoor Unit

  • S-18PUB5H59B

Model Outdoor Unit

  • U-18PNB5H59

Panel

  • CZ-KPUB5H9

Capacity Rated

  • Cooling

    • W
      • 5276
    • Btu/hr
      • 18002

ISEER

  • 4.0

Star Rating

  • 3

Electrical Rating

  • Cooling

    • Running Current (A)
      • 5.87
    • Power Input (W)
      • 1320

Power Source

  • V/Phase/Hz

    • 230V / 1ɸ / 50Hz

Indoor Unit

  • Air Volume

    • H/M/L (CMH)
      • 1300/1050/950
  • Sound Pressure Level

    • H/M/L dB(A)
      • 43/42/40
  • Dimension

    • Indoor LxBxH (cm)
      • 84.5 x 84.5 x 24.5
    • Panel LxBxH (cm)
      • 95.0 x 95.0 x 4.2
  • Net Weight

    • Indoor Unit / Panel (kg)
      • 23.7/5.5

Outdoor Unit

  • Sound Pressure Level

    • dB(A)
      • 56
  • Dimension

    • LxBxH (cm)
      • 81.0 x 30.1 x 59.4
  • Net Weight

    • Kg
      • 38.7
  • Refrigerant Type

    • R-32

Piping Connection

  • Gas (Flare)

    • cm (inches)
      • 1.27 (1/2")
  • Liquid (Flare)

    • cm (inches)
      • 0.635 (1/4")
  • Drain

    • cm
      • 3.2

Ambient Temperature Operating Range

  • °C

    • up to 50°C

Standard Remote Controller

  • LCD Wireless Type

Compressor Type

  • Rotary
