• Pump cover with smooth curve for elegant outlook
• Brass-made casing cover and impeller are resistance to friction and high temperature that allow smoother water stream
• Nitrogen Gas is adopted in accumulator for stable and optimum performance
• Rubber Bladder made of pliable material butyl that is strong enough to produce a more stable pressure
Structure
• Accumulator is a compression space containing Nitrogen Gas which has characteristics of elasticity. The gas content will never deplete that always stay stable and optimum
• Rubber Bladder is made of Butyl that is stainless and anti-leakage.It functions as water separator with the Nitrogen compression room.
• Automatic Switch equipped with a protector made of fire-retardantmaterial and a Platinum-made Switch that is long-lasting. If functions to break the steam if the water stream is closed.
Reliable and Safe
• Equipped with Thermal Protector (130°C) enchances security against burning by turning off the pump directly
• Double stator protection being resistant to abrasion reduce the danger of short circuit
Durable
• High accurate rotor with anti-rust layer allows operation up to 8,000 hours without stopping
• Stainless aluminum motor body and brass casing cover allow high durability
• Auto system with platium equipped switch can operate 1 million on/off without performance reduced
Installation and Selection
To get the right pump for the job, following criteria should be determined
1) Required amount of water
2) Suction Head - The Vertical distance from water level to the centerline of the pump
3) Discharge Head -The vertical distance from the centerline of the pump to final discharge outlet
4) Friction Loss - Resistance and loss of pressure due to the flow of water pass through the pipes and fittings with the pump system
*Friction loss can be found from reference table for standard pipe supplies and manufacturer-provided charts for particular parts respectively
5) Total Dynamic Head - Suction Head + Discharge Head + Friction Loss
Once the values are determined, the pump can be sized according to Required Amount of Water and Total Dynamic Head from Pump
Characteristic Chart.
