| AMPLIFIER |
Amp Type |
2ch Amp |
| RMS Output Power |
Front Ch |
40W Per Channel |
| Total RMS Stereo mode power |
80W |
| NOTE |
*1 Download on the App Store. Download on Google Play™. |
| NOTE |
*2 Package Remarks: ARC (Audio Return Channel) compatible TV is required. |
| NOTE |
*3 Specifications are subject to change without notice. All numbers given here are approximate. |
| Front Speaker |
Type |
1 way, 1 speaker system(Bass reflex) |
| Speaker Unit |
Full range (10×4)cm x2 |
| Bass Expand |
Bass Reflex |
| NETWORK |
Bluetooth |
Version |
Bluetooth® Ver 2.1 + EDR |
| Class |
Class 2 |
| Codec, SBC |
yes |
| Bluetooth standby |
yes |
| Connectivity, Multi-Pairing |
yes (MAX 8 Devices) |
| Music Streaming App*1 |
iOS |
yes |
| Android |
yes |
| SOUND FUNCTION |
Surround |
Virtual Surround |
yes |
| SOUND MODE |
STANDARD, MUSIC, CINEMA |
| DECORDER FUNCTION |
Dolby Digital |
yes |
| DTS Digital Surround |
yes |
| HDMI FUNCTION |
CEC |
yes |
| Audio Return Channel(for HDMI Output) |
yes*2 |
| USB FUNCTION |
Battery Charge |
500mA |
| USB Port for Service Use |
yes |
| USB Port for Customer Software Update |
yes |
| TERMINALS |
USB Port |
yes (1) |
| HDMI |
Output |
yes (1) |
| Audio Input |
Optical Digital Input |
yes |
| MAIN UNIT SETTING |
TV Size for Fitting |
40 inch |
| GENERAL |
Power Supply |
AC 220 - 240V, 50Hz |
| Power Consumption |
Normal Use |
15W*3 |
| Normal Standby |
0.5W*3 |
| Bluetooth Standby |
2.0W*3 |
| Network Standby |
Under 2W*3 |
| LED Dimmer |
yes |
| Auto Power OFF |
yes |
| Main Unit |
Dimensions (W x H x D) |
450 x 51 x 135mm |
| Weight |
1.6Kg |
| REMARKS |
Consider world wide design, except USA. For example, for Taiwan market and wide-range power supplier design. |
