CS-CU-Z42VKR
295 x 919 x 194mm
Specs
Model
-
CS/CU-Z42VKR
Cooling Capacity (kW)
-
4.20 (0.90~5.00)
Heating Capacity (kW)
-
5.10 (0.90~7.10)
Air Flow (L/s)
-
222
222
Dehumid (L/h)
-
2.4
Running Current (A)
-
4.7
5.9
Power Input (kW)
-
1.07 (0.22~1.60)
1.34 (0.23~2.25)
AEER/EER (W/W)
-
3.88/3.93
ACOP/COP (W/W)
-
3.77/3.81
Star Rating
-
3
3
Inside Sound Pressure Level (dB) (Hi/Lo/S-Lo)
-
47/30/23
46/31/27
Outside Sound Pressure Level (dB) (Hi/S-Lo)
-
47/42
47/42
Sound Power Level (dB) (Hi/S-Lo)
-
62/57
62/57
Net Weight - Indoor (Outdoor)
-
10kg (43kg)
Dimensions - Indoor (Outdoor) (h x w x d)
-
295 x 919 x 194mm
(695 x 875 x 320mm)
Refrigerant Pipe Diameter - Liquid Side (mm/(in))
-
6.35
(1/4)
Refrigerant Pipe Diameter - Gas Side (mm/(in))
-
12.7
(1/2)
Pipe Extension Length Min~Max (m)
-
3~30
Pipe Length for Additional Gas (m)
-
7.5
Additional Gas Amount (g/m)
-
15
Power Supply
-
Outdoor
Operating Range (Outdoor) - Cooling (°C)
-
+5~+46
Operating Range (Outdoor) - Heating (°C)
-
-15~+24
Refrigerant Type
-
R32
