Robust and durable for
continuous 24 hour operation
The highly durable panel can be operated continuously
for 24/7. It makes the display panel suitable for
use all day and night in places such as surveillance stations
and public facilities. A built-in cooling fan automatically
operates (when set to Auto) depending on the temperature.
This prevents overheating in the upper screens of a
multi-screen installation, which are easily subject
Slim even with the optional
metal cover frame
Attaching the optional 0.4mm metal cover frame to
the unit provides even stronger protection against
impacts. The screw holes for attaching the frame
cannot be seen, so they do not adversely affect the
beauty of the display.
Direct-lit LED backlight with
high brightness of 800-cd/m2
Direct-lit LED backlight construction with full-screen
LED layout enables Industry's top class of brightness
800 cd/m2. Black reproduction is maintained in dark
areas while bright areas are displayed more brightly
to achieve a high level of contrast.
Wide viewing angle for sharper
images from left and right angles
The IPS panel has a wide viewing angle, so colours
don't change when the image is viewed from
right or left angles. This allows information to be
accurately relayed in large public areas.
Flexible installation for either
vertical or horizontal display
The display can be installed either horizontally
or vertically to match the content and installation
location without being affected by "Mura" (unevenness).
This is because the display has relatively uniform pressure
distribution as c ompared to a TV panel, which results
in far better stability. Regardless of the installation
direction, the lamp life stays the same since a constant
operating temparature is maintained.
Super narrow 5.3mm thin bezel
means joints perfect for video walls
The super-narrow bezel results in joints that are
only 5.3 mm (0.21") wide for video wall installations.
Even in large-screen configurations, the screen
borders can barely be seen, so images are powerful
Multi-screen system dynamically
displays images in large spaces
The Multi-Display function enlarges images up to
five times their original size, both vertically & horizontally.
It enlarges images by the same zoom ratio in both vertical
and horizontal directions, such as 2x2, 3x3, 4x4, 5x5, or by
different ratios in order to effectively use vertically or
horizontally elongated display locations.
for up to 10 displays
Signals can be distributed to as many as 10 displays
from a single DVI input. When ID numbers have been
assigned to displays in advance, any designated display
can be operated by a single remote control.
Anti glare layer reduces glare and
suppresses ambient light reflection
The AG layer scatters light reflected from the sun
or illumination to reduce glare. This provides
greater visibility. It is ideal for use in surveillance
stations and public facilities.
User memory function
stores colour adjusted data
The user can store colour adjusted data in the
main unit memory. By simply retrieving the
stored data, the unit can be re-installed
without bothersome callibration*.
* There are cases, however, when the visual
adjustments are needed once the video wall
Colours are pre-calibrated prior to factory
shipment, minimising colour differences
between displays for multi-screen use. This allows
the creation of single images without any visible
differences from display to display. Adjustments
may be required at time of video wall installation.
The screen saver reduces the possibility of
afterimages or image retention that can
occur when displaying still images with
constant, unchanging brightness for long
periods of time.
Power-on delay function
For video walls and other multi-unit applications,
this function automatically shifts the power-on
time slightly for each display unit in the system,
so there's less load on the power supply.
Automatic picture positioning
Simply press the Auto Setup key on the remote
control to position the picture. The adjustment
results in optimal standard values for horizontal
and vertical picture sizes.
1:1 Pixel mode
The 1:1 Pixel mode maps the 1920 × 1080
video content to full-HD panel pixels to display
100% of the original content. By skipping the
scaling process, this mode is able to produce
high-definition images in their original,
1:1 pixel form.
